Compact Desktop Measurement Box

Compact desktop measurement box

Compact desktop measurement box header

Compact Desktop Measurement Box

Shielded box for testing. Working size 350(W)*400(D)*300(H)

Compact desktop measurement box (350 x 400 x 300 mm)
  • An ideal solution for Bluetooth, WiFi, 3G/4G phones testing
  • High isolation
  • Easy & Flexible operation

  • High levels of shielding attenuation, greater than 75 dB
  • Box can be equipped with shielded power filters for power connection in the box while still blocking all wireless signals.
  • Easy & Flexible operation in Lab and production line
  • R&D, custom design

Technical specifications
Shielding effectMore than 70 dB
Interface typeType 2, Type 4
Numbers of filters3 pcs
Working temperature (°C)Operates at room temperature
Working dimensions (mm)350(W)*400(D)*300(H)
Outer dimensions (mm)430(W)*538(D)*366(H)
Weight (kg)20 kg
Colour of appearanceBeige
* Notice: dimensions are indicative
Technical drawing
Compact desktop measurement box technical drawing
