A fence and a removable cover creating a very rigid shielding can for printed circuit boards. The fence need to be fixed to the PCB with SMD clips
EMI screening covers (shielding cans) for PCB’s were developed to shield certain parts of electronic equipment from electromagnetic radiation at the source, than all the components in the entire housing.
EMI shielding cans are available in standard sizes, or can be produced to customer specification within short turn around time.
Whether you require a small quantity of prototypes or large production runs, we can supply the precision components you require.
High performance Clip-on PCB shielding can
High performance PCB shields consisting of partial two layers that together form a solid and double-walled PCB shield.
The lid and fence work together in one stroke that results a very tight closure of the lid around the fence resulting to very high shielding performance also for lower frequencies.
Very important for applications requiring shielding for lower frequencies. The double wall has more body than a single walled PCB shield and also works better at lower frequencies.
Mounting clips
Standard sizes
NOTE: Custom sizes and shapes can be produced on request and according to your drawing. Send your drawing by e-mail to request a quote.
Square fixed PCB shielding cans (1 to 10 mm height)
| Length A (mm) | Width B (mm) | Height C (mm) | ||||
| 1 | 2 | 3 | 5 | 10 | ||
|---|---|---|---|---|---|---|
| 10 | 10 | 1505-10-10-1 | 1505-10-10-2 | 1505-10-10-3 | 1505-10-10-5 | 1505-10-10-10 |
| 15 | 15 | 1505-15-15-1 | 1505-15-15-2 | 1505-15-15-3 | 1505-15-15-5 | 1505-15-15-10 |
| 20 | 20 | 1505-20-20-1 | 1505-20-20-2 | 1505-20-20-3 | 1505-20-20-5 | 1505-20-20-10 |
| 25 | 25 | 1505-25-25-1 | 1505-25-25-2 | 1505-25-25-3 | 1505-25-25-5 | 1505-25-25-10 |
| 30 | 30 | 1505-30-30-1 | 1505-30-30-2 | 1505-30-30-3 | 1505-30-30-5 | 1505-30-30-10 |
| 35 | 35 | 1505-35-35-1 | 1505-35-35-2 | 1505-35-35-3 | 1505-30-30-5 | 1505-30-30-10 |
| 40 | 40 | 1505-40-40-1 | 1505-40-40-2 | 1505-40-40-3 | 1505-40-40-5 | 1505-40-40-10 |
Rectangular PCB shielding cans (1 to 15 mm height)
| Length A (mm) | Width B (mm) | Height C (mm) | ||||
| 1 | 2 | 3 | 5 | 10 | ||
| 10 | 15 | 1505-10-15-1 | 1505-10-15-2 | 1505-10-15-3 | 1505-10-15-5 | 1505-10-15-10 |
| 10 | 20 | 1505-10-20-1 | 1505-10-20-2 | 1505-10-20-3 | 1505-10-20-5 | 1505-10-20-10 |
| 10 | 25 | 1505-10-25-1 | 1505-10-25-2 | 1505-10-25-3 | 1505-10-25-5 | 1505-10-25-10 |
| 10 | 30 | 1505-10-30-1 | 1505-10-30-2 | 1505-10-30-3 | 1505-10-30-5 | 1505-10-30-10 |
| 10 | 35 | 1505-10-35-1 | 1505-10-35-2 | 1505-10-35-3 | 1505-10-35-5 | 1505-10-35-10 |
| 10 | 40 | 1505-10-40-1 | 1505-10-40-2 | 1505-10-40-3 | 1505-10-40-5 | 1505-10-40-10 |
| 10 | 45 | 1505-10-45-1 | 1505-10-45-2 | 1505-10-45-3 | 1505-10-45-5 | 1505-10-45-10 |
| 10 | 50 | 1505-10-50-1 | 1505-10-50-2 | 1505-10-50-3 | 1505-10-50-5 | 1505-10-50-10 |
| 15 | 20 | 1505-15-20-1 | 1505-15-20-2 | 1505-15-20-3 | 1505-15-20-5 | 1505-15-20-10 |
| 15 | 25 | 1505-15-25-1 | 1505-15-25-2 | 1505-15-25-3 | 1505-15-25-5 | 1505-15-25-10 |
| 15 | 30 | 1505-15-30-1 | 1505-15-30-2 | 1505-15-30-3 | 1505-15-30-5 | 1505-15-30-10 |
| 15 | 35 | 1505-15-35-1 | 1505-15-35-2 | 1505-15-35-3 | 1505-15-35-5 | 1505-15-35-10 |
| 15 | 40 | 1505-15-40-1 | 1505-15-40-2 | 1505-15-40-3 | 1505-15-40-5 | 1505-15-40-10 |
| 15 | 45 | 1505-15-45-1 | 1505-15-45-2 | 1505-15-45-3 | 1505-15-45-5 | 1505-15-45-10 |
| 15 | 50 | 1505-15-50-1 | 1505-15-50-2 | 1505-15-50-3 | 1505-15-50-5 | 1505-15-50-10 |
| 20 | 25 | 1505-20-25-1 | 1505-20-25-2 | 1505-20-25-3 | 1505-20-25-5 | 1505-20-25-10 |
| 20 | 30 | 1505-20-30-1 | 1505-20-30-2 | 1505-20-30-3 | 1505-20-30-5 | 1505-20-30-10 |
| 20 | 35 | 1505-20-35-1 | 1505-20-35-2 | 1505-20-35-3 | 1505-20-35-5 | 1505-20-35-10 |
| 20 | 40 | 1505-20-40-1 | 1505-20-40-2 | 1505-20-40-3 | 1505-20-40-5 | 1505-20-40-10 |
| 20 | 45 | 1505-20-45-1 | 1505-20-45-2 | 1505-20-45-3 | 1505-20-45-5 | 1505-20-45-10 |
| 20 | 50 | 1505-20-50-1 | 1505-20-50-2 | 1505-20-50-3 | 1505-20-50-5 | 1505-20-50-10 |
| 25 | 30 | 1505-25-30-1 | 1505-25-30-2 | 1505-25-30-3 | 1505-25-30-5 | 1505-25-30-10 |
| 25 | 35 | 1505-25-35-1 | 1505-25-35-2 | 1505-25-35-3 | 1505-25-35-5 | 1505-25-35-10 |
| 25 | 40 | 1505-25-40-1 | 1505-25-40-2 | 1505-25-40-3 | 1505-25-40-5 | 1505-25-40-10 |
| 25 | 45 | 1505-25-45-1 | 1505-25-45-2 | 1505-25-45-3 | 1505-25-45-5 | 1505-25-45-10 |
| 25 | 50 | 1505-25-50-1 | 1505-25-50-2 | 1505-25-50-3 | 1505-25-50-5 | 1505-25-50-10 |
| 30 | 35 | 1505-30-35-1 | 1505-30-35-2 | 1505-30-35-3 | 1505-30-35-5 | 1505-30-35-10 |
| 30 | 40 | 1505-30-40-1 | 1505-30-40-2 | 1505-30-40-3 | 1505-30-40-5 | 1505-30-40-10 |
| 30 | 45 | 1505-30-45-1 | 1505-30-45-2 | 1505-30-45-3 | 1505-30-45-5 | 1505-30-45-10 |
| 30 | 50 | 1505-30-50-1 | 1505-30-50-2 | 1505-30-50-3 | 1505-30-50-5 | 1505-30-50-10 |
| 35 | 40 | 1505-35-40-1 | 1505-35-40-2 | 1505-35-40-3 | 1505-35-40-5 | 1505-35-40-10 |
| 35 | 45 | 1505-35-45-1 | 1505-35-45-2 | 1505-35-45-3 | 1505-35-45-5 | 1505-35-45-10 |
| 35 | 50 | 1505-35-50-1 | 1505-35-50-2 | 1505-35-50-3 | 1505-35-50-5 | 1505-35-50-10 |
